English The DWR-206 series is calibrated for falling pressure. This means that the adjustable switching pressure on the scale corresponds to the switching point at falling pressure. The reset point is higher by the amount of the switching difference. Minimum pressure limiter DWR6-206 for hot water, steam, gas, liquid fuels (DWR).
Technical data:
Setting range: 0.5 - 6.0 bar
Pressure type: Overpressure, relative
Pressure connection: Female thread G¼“, male thread G½”
Electrical connection: Plug according to DIN EN 175301
Protection class: IP54
Switch housing material: Sturdy housing made of seawater-resistant die-cast aluminium GD Al Si 12
Materials in contact with the medium: Stainless steel
Medium temp.: -25 ... 70 °C
Max. medium temperature: Short-term temperatures up to 85 °C are permissible. Higher medium temperatures are possible if suitable measures (e.g. water pocket pipe) are taken to ensure that the above limit values are not exceeded at the switch device (see accessories for pressure switches/transmitters)
Ambient temperature: -25 ... 70 °C
Note on ambient temperature: At ambient temperatures below 0 °C, ensure that no condensation can form in the sensor and switching device.
Switching function: 8 A at 250 V AC, 5 A at 250 V AC inductive, 8 A at 24 V DC, 0.3 A at 250 V DC
Additional functions (optional):
-213: gold-plated contacts, single-pole switching (not available with adjustable switching differential, among other things. Switching capacity: max. 24 VDC, 100 mA, min. 5 V DC, 2mA
-301: Terminal connection housing, IP65
-513: Gold-plated contacts, single-pole switching. Fixed switching differential. IP65. Switching capacity: max. 24 Vdc, 100 mA, min. 5 Vdc, 2 mA, suitable isolating switching amplifier required, degree of protection Ex-i
Registrations:
TV.DWFS (SDBFS).17-281 in accordance with VdTUEV bulletin 100, edition 03.2017 and DIN EN 12952-11 and DIN EN 12953-9:2007
ID 0000035004 in accordance with DIN EN 764-7:2002 and DIN EN 13611:2015-09
CE-0085CL0343 according to DIN EN 1854, edition 01.10.2010
SIL2 according to IEC 61508-2
Medium: hot water, steam, gas, fuel gas
Scale calibration increasing pressure
Technical data:
Setting range: 0.5 - 6.0 bar
Pressure type: Overpressure, relative
Pressure connection: Female thread G¼“, male thread G½”
Electrical connection: Plug according to DIN EN 175301
Protection class: IP54
Switch housing material: Sturdy housing made of seawater-resistant die-cast aluminium GD Al Si 12
Materials in contact with the medium: Stainless steel
Medium temp.: -25 ... 70 °C
Max. medium temperature: Short-term temperatures up to 85 °C are permissible. Higher medium temperatures are possible if suitable measures (e.g. water pocket pipe) are taken to ensure that the above limit values are not exceeded at the switch device (see accessories for pressure switches/transmitters)
Ambient temperature: -25 ... 70 °C
Note on ambient temperature: At ambient temperatures below 0 °C, ensure that no condensation can form in the sensor and switching device.
Switching function: 8 A at 250 V AC, 5 A at 250 V AC inductive, 8 A at 24 V DC, 0.3 A at 250 V DC
Additional functions (optional):
Registrations:
Medium: hot water, steam, gas, fuel gas
Scale calibration increasing pressure
