English ABIC Gas-Fired Forced-Draft Burner Type: GE 50 E 0.5 K
Fully automatic design with UV monitoring, single-stage operation.
Technical Specifications:
Burner output: 19–60 kW
Gas type: Natural gas
Calorific value Hu: 10.8 kWh/m³
Required gas flow pressure: 20 mbar (20-100 mbar)
Gas flow rate: 1,7 - 5,8 m³/h
Gas connection fitting: 1/2"
Voltage 230 V, +10%, -15%, 50 Hz.
Burner fully compliant with EN 676.
Cast aluminum housing, low-noise high-performance blower with a speed of 2800 rpm. Independent control elements for gas and combustion air. 1/2" gas valve assembly in compact design MB DLE 405 B 01S20 consisting of:
Gas pressure monitor, gas pressure regulator, gas filter, gas solenoid valve with main flow adjustment, 2nd gas solenoid valve as a safety valve.
• Air pressure switch
• High-voltage ignition transformer with spark suppression
• Ignition electrode
• Plug-in burner control unit with reset button; monitoring of the ignition process as well as the pilot and main flames is based on the UV principle.
• Special burner mixing device suitable for the combustion of all gases in accordance with DVGW Worksheet G 260.
• Pre-wired and ready for connection with a 7-pin connector.
Delivery time approx. 3–6 weeks, depending on configuration.
